10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works

10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works
10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works
10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works

Large Image :  10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works

Product Details:
Place of Origin: China
Brand Name: HUIHAO CUSTOM
Certification: ISO
Model Number: HVAC Ducting Insulation Weld Pins
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Packaging Details: 1. 2000 pcs / 3000 pcs/ 5000 pcs per carton 2. 36 cartons per pallet 3. or according to your requirement.
Delivery Time: 5-8 work days
Payment Terms: L/C,T/T,Western Union,paypal
Supply Ability: 5,000,000pcs per 30 days
Contact Now

10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works

Description
Product Name: HVAC Ducting Insulation Weld Pins Material: Galvanized Steel
Brand: HUIHAO CUSTOM Head Dia: 30mm
Usage: Duct Wrap Or Duct Liner Fastening Works Pin Diameter: 2.7mm, 3.0mm, 3.4mm
Samples: Supported Pin Length: 25mm, 38mm, 50mm, 75mm, 100mm Etc.
Highlight:

Duct Liner Fastening Weld Pins

,

Duct Wrap Weld Pins

,

10Gauge HVAC Ducting Insulation Weld Pins

10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works
Product Specifications
Attribute Value
Product name HVAC Ducting Insulation Weld Pins
Material Galvanized Steel
Brand HUIHAO CUSTOM
Head Dia 30mm
Usage Duct Wrap Or Duct Liner Fastening Works
Pin Diameter 2.7mm, 3.0mm, 3.4mm
Samples supported
Pin Length 25mm, 38mm, 50mm, 75mm, 100mm etc.
Product Description

10Gauge HVAC Ducting Insulation Weld Pins are used to fasten insulation to the inside of sheet metal air ducts. These fasteners are usually applied when the ductwork is being fabricated.

The fasteners have been specifically designed to work with all currently available duct liners and standard resistance welding type application equipment. Beveled edge cap prevents tearing of duct liner.

If you are in need of HVAC Ducting Insulation Weld Pins, please feel free to ask me a price, or sample, my email is cherry@huihaomesh.com
  • Item: 10Gauge HVAC Ducting Insulation Weld Pins
  • Head Material: Galvanized steel
  • Head Edge: Beveled edge washer to prevent cutting of insulation material
  • Head Diameter: 30mm
  • Head Base: 0.5mm
  • Type: With Insulated Paper Or Insulated Film
  • Pin Material: Galvanized steel or copper coated steel
  • Pin Diameter: 2.7mm, 3.0mm, 3.4mm etc.
  • Pin Length: 25mm, 38mm, 50mm, 75mm, 100mm, 120mm etc.
10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 0
The Importance Of HVAC Ducting Insulation

HVAC installations have to maintain the temperature and heat loss of the air at the specified level when transporting warm air through long ventilation ducts. It is important you keep both criteria at desired level to minimise energy loss.

Ducts that transport cool air also need a good thermal insulation solution. The insulation maintains the lower temperature inside the duct by insulating it from the warmer ambient air temperature. If the cool air in the duct is heated by the surrounding air, the HVAC system functions less effectively and you will need more energy to maintain the duct's correct temperature.

If the ducts are properly insulated, the whole ventilation system will work as designed and you need less equipment calibration. HUIHAO offers a wide range of products for these insulation applications such as insulation pins and clips, self adhesive fasteners, Cupped head pins and welding machines.

10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 1
Application Of The HVAC Ducting Insulation Weld Pins
10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 2
  • Item: HVAC Ducting Insulation Weld Pins
  • Application: used for fastening insulation material on metal surface
  • Step:
    1. Hanging the insulation
    2. Directly weld the weld pins through the insulation materials
Recommended for Pin length before welding
1/2" insulation(all densities) 12.67mm
1" insulation(1-1/2"ib density) 17.63mm
1" foam 25.55mm
1" insulation(3ib densities) 23.72mm
1-1/2" insulation(all densities) 28.42mm
2" insulation(1-1/2"-2" ib density) 37.95mm
2" insulation(3ib densities) 48.77mm
3" insulation(all densities) 69.85mm
4" insulation(all densities) 95.00mm
Package Of The HVAC Ducting Insulation Weld Pins
  • 2000 pcs / 3000 pcs/ 5000 pcs per carton
  • 48 cartons per pallet
  • or according to your requirement
10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 3 10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 4
Certificate Of Hardware Mesh Product Limited
10 Gauge HVAC Ducting Insulation Weld Pins For Duct Wrap Or Duct Liner Fastening Works 5
1. Are you a manufacture or a trader?

We are a manufacture, located in Hebei province, China.

2. Do you support product customization?

Yes, the material and the size all could be customized.

3. Can I get samples?

Yes, we have free samples for you to check the quality.

4. How do you control and ensure product quality?
  1. Confirm with you every details before quoting.
  2. Before production, we will reconfirm all the details again.
  3. During production, we strictly implement "IATF 16949 Quality Management System" standard.
  4. We will send you videos and pictures during the production and shipment process.
5. What's your advantages?

Cooperate with us, we can ensure:

  1. Competitive price: we sale what we manufacture.
  2. On-time delivery: we have the auto-production line to ensure the on-time delivery.
  3. Excellent quality: we have rich experience, our products are in line with international standard.
  4. Good after-sale service: we offer good after-sale service for each order.
