Length Customizable Bi Metallic Stud Welding Pins Used With Capacitor Discharge Spot Welder For Ship Bulkhead Insulation Work

Large Image : Length Customizable Bi Metallic Stud Welding Pins Used With Capacitor Discharge Spot Welder For Ship Bulkhead Insulation Work

Product Details:

Place of Origin:	china
Brand Name:	HUIHAOCUSTOM
Certification:	ISO9001-2015
Model Number:	Bi Metallic Stud Pins

Payment & Shipping Terms:

Minimum Order Quantity:	10000 pcs
Packaging Details:	500 pcs per pp bag, 10 bags per carton for BI-Metallic Stud Pins
Delivery Time:	8 work days
Payment Terms:	L/C,T/T
Supply Ability:	30000pcs per day

Contact Now

Length Customizable Bi Metallic Stud Welding Pins Used With Capacitor Discharge Spot Welder For Ship Bulkhead Insulation Work

Description

Name:	Bi Metallic Stud Welding Pins	Factory:	Hebei Huihao Company
Base Material:	Aluminum	Base Size:	6x15mm
Pin Material:	Stainless Steel	Pin Diameter:	3mm
Install Parts:	Self Locking Washers	Pin Length:	As Your Requirement
Highlight:	2" stud welding pins , ship buiding industry stud welding pins , capacitor discharge weld pins bi metallic

Bi Metallic Stud Welding Pins for Ship Bulkhead Insulation

Product Specifications

Manufacturer:

Hebei Huihao Company

Base Material:

Aluminum

Base Size:

6mm × 15mm

Pin Material:

Stainless Steel

Pin Diameter:

3mm

Installation Parts:

Self-locking washers

Pin Length:

Customizable to requirements

Standard Sizes Available

Base Material	Pin Material	Diameter	Length
Aluminum	Stainless steel/copper coated mild steel	3mm	50mm
Aluminum	Stainless steel/copper coated mild steel	3mm	65mm
Aluminum	Stainless steel/copper coated mild steel	3mm	70mm
Aluminum	Stainless steel/copper coated mild steel	3mm	85mm
Aluminum	Stainless steel/copper coated mild steel	3mm	90mm
Aluminum	Stainless steel/copper coated mild steel	3mm	100mm
Aluminum	Stainless steel/copper coated mild steel	3mm	110mm
Aluminum	Stainless steel/copper coated mild steel	3mm	130mm
Aluminum	Stainless steel/copper coated mild steel	3mm	150mm
Aluminum	Stainless steel/copper coated mild steel	3mm	160mm
Aluminum	Stainless steel/copper coated mild steel	3mm	180mm

Product Features

Designed for marine insulation applications, particularly ship bulkhead insulation fastening
Aluminum weld base compatible with capacitor discharge welding process
Can also be used with short cycle drawn arc weld process on thicker aluminum plate
Tip ignition designed specifically for capacitor discharge welding
Stud flange conforms to EN ISO 13918 standard
Durable aluminum base material with optimal hardness
Available with stainless steel or copper coated mild steel pins
Compatible with various self-locking washers in multiple sizes and materials

Packaging Options

Standard packaging includes:

100, 200, 300, or 500 pieces per plastic bag (depending on pin length)
10 bags per carton box
Packed on pallets for shipping

Custom packaging options available upon request.

Frequently Asked Questions

Are you a manufacturer or a trader?

We are a manufacturer located in Hebei province, China.

Do you support product customization?

Yes, we can customize materials, sizes, and packaging according to your specific requirements.

How can I get samples?

For standard products: We provide free samples for orders under $5.

For custom products: We charge 1-3 times the unit price based on specifications.

Shipping via DHL, FedEx, TNT, UPS, or EMS at customer's expense.

Samples are dispatched immediately upon payment confirmation.

How do you ensure product quality?

Our quality assurance process includes:

Detailed confirmation of specifications before quoting
Final reconfirmation of all details after order placement
Strict adherence to IATF 16949 Quality Management System standards
Regular production updates with photos and videos
