>>> Introduction To The Flanged Stud Welding Pins

1.Flanged Stud Welding Pins are designed to be welded to thin gauge sheet material using tip ignition according to the      capacitors discharge welding process.

2.Flanged Stud Welding Pins are available in many different sizes, from a base diameter of a 2 mm stud up to 12 mm.

3.Standard material for flanged Stud Welding Pins are: Copper Plated Steel, Stainless Steel, Aluminum

• Stainless Steel AISI grade - 302/304/305 std. Other grades available upon request.
• Aluminum ALLOY - 1100 & 5000 seriesOther alloys available upon request.
• Brass ALLOY - (lead free) 70-30 std. Other alloys available upon request.

4.The stud flange is designed according to EN ISO 13918.

5.Studs made of steel 4.8 are protected against corrosion by copper coating. (Thickness : 3 to 5 µm)

Imperial Thread Flanged Stud Welding Pins

>>>specification of The Flanged Stud Welding Pins

d               dk               k                                        L DIA MAX MIN MAX MIN MAX MIN 8mm,10mm,12mm,16mm,20mm,25mm,30mm 3 2.87 3.13 4.65 4.35 1.3 0.7 4 3.85 4.15 5.65 5.35 1.3 0.7 5 4.85 5.15 6.68 6.32 1.4 1.1 6 5.85 6.15 7.68 7.32 1.4 1.1
