Stainless Steel Insulation Anchor Pins For Cooling Insulation Covers

Large Image : Stainless Steel Insulation Anchor Pins For Cooling Insulation Covers

Product Details:

Place of Origin:	China
Brand Name:	Huihaokasite
Certification:	ISO9001-2015
Model Number:	lacing anchor

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	USD0.06-USD0.12/PC
Packaging Details:	paper carton + wood pallet
Delivery Time:	15 days after the payment
Payment Terms:	L/C,T/T,Western Union,Paypal
Supply Ability:	500000 pcs per 15 days

Contact Now

Stainless Steel Insulation Anchor Pins For Cooling Insulation Covers

Description

Material:	Stainless Steel , Galvanized Steel. Mild Steel	Head:	7/8" As Standard
Spindle Dia:	12ga Or 14ga As Standard	Length:	2-1/2" Or 4-1/2" As Standard
Head Thickness:	1mm	Application:	Removable Insulation Jacket
Highlight:	duct insulation pins , insulation anchors

Stainless Steel Insulation Anchor Pins For Cooling Insulation Covers

Product Specifications

Attribute	Value
Material	Stainless steel, galvanized steel, mild steel
Head	7/8" as standard
Spindle Dia	12ga or 14ga as standard
Length	2-1/2" or 4-1/2" as standard
Head thickness	1mm
Application	Removable Insulation Jacket

Detailed Specifications

Product name	Insulation lacing anchors pins
Head diameter	22mm, 30mm
Hook size	5mm x 11mm
Head material thickness	1mm
Pin diameter	2.2mm, 2.7mm, 3mm
Pin length	25.4mm - 140mm

Materials: stainless steel, galvanized steel and mild steel
Fixing parts: Self-locking washers, speed clips and dome cap washers, or to your request

International Standards

US Standard	EU Standard	Australia Standard
Head diameter is 1" Pin diameter is 10Ga Length options: 1/2" - 2"	Head diameter is 30mm Pin diameter is 2.7mm Length options: 22mm - 100mm Some customers require kraft paper under head or plastic sleeve on pin	Customers may require US or EU standard weld pins Some require 14Ga pin Common lengths: 25mm, 50mm, 75mm, 100mm Lacing anchors marked NO AB to indicate asbestos-free blanket

Types of Cooling Insulation Covers Lacing Anchors

Installation Instructions

Prepare the insulation blanket or removable cover

Press the lacing anchor through the insulation

Press the self locking washer into the pin to fasten the insulation

Bend over or clip off the pin

Install the insulation blanket or removable cover

Lace the hook by lacing tie to fasten the insulation

Applications

Stainless steel material lacing anchors are widely used for fixing:

Exhaust insulation blankets
Fabric expansion joints
Temptec exhaust blankets
Mat insulation
Thermal insulation covers
Cooling insulation covers
Heat insulation covers

Freeze protection cover
Removable insulation covers
Tank insulation cover
Flange leak insulation covers
Offshore production cover
Heat-shield insulation blankets
Removable insulation jacket
