Product Details:
|
| Material: | Galvanized Steel Stainless Steel As Standard | Diameter: | 8mm As Standard |
|---|---|---|---|
| Length: | 50mm 70mm 90mm 110mm 140mm 170mm Etc. | Base Size: | 35mm As Standard |
| Thickness: | 0.7mm | Application: | Fixing Celotex, Kingspan, Rockwool Products |
| High Light: | duct insulation pins,insulation anchors |
||
Material: Stainless steel/galvanized steel
Nail dimater :8mm
Nail length: 50mm/60mm/80mm/90mm /110mm/140mm/ 170mm/230mm/300mm, etc
Plate size: 35mm
|
Pin size |
Pin diameter |
Pin length |
Plate size |
Plate thickness |
Packaging (carton) |
|
8*50 |
8mm |
50mm |
30/35mm |
0.7mm |
250pcs |
|
8*60 |
8mm |
60mm |
30/35mm |
0.7mm |
250pcs |
|
8*90 |
8mm |
90mm |
30/35mm |
0.7mm |
250pcs |
|
8*110 |
8mm |
110mm |
30/35mm |
0.7mm |
250pcs |
|
8*140 |
8mm |
140mm |
30/35mm |
0.7mm |
250pcs |
|
8*170 |
8mm |
170mm |
30/35mm |
0.7mm |
250pcs |
|
8*230 |
8mm |
230mm |
30/35mm |
0.7mm |
250pcs |
|
8*300 |
8mm |
300mm |
30/35mm |
0.7mm |
250pcs |
The metal insulation anchors are suit for concrete, natural stone with dense structure, solid brick, solid sand-lime brick, solid block made from lightweight concrete, aerated concrete, vertically perforated brick, perforated sand-lime brick etc.
The metal insulation anchors also suit for the soft and pressure-resistant insulating materials, such as glass wool, rock wool, polystyrene, PU panels, foam glass, lighting building boards made of wood wool, coir matting, cork boards etc.
Quick and simple hammerset installation saves work
No additional screws or nails. Also suitable for ceiling soffits
Fire-resistant according to DIN 4102 (class A1)
Fire protection report for the galvanised version with anchoring depth hef > 50 mm
