M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface

M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface

Large Image :  M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface

Product Details:
Place of Origin: China
Brand Name: HUIHAO CUSTOM
Certification: ISO
Model Number: Air Duct Insulation Pins
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Packaging Details: 1. 2000 pcs / 3000 pcs/ 5000 pcs per carton 2. 36 cartons per pallet 3. or according to your requirement.
Delivery Time: 5-8 work days
Payment Terms: L/C,T/T,Western Union,paypal
Supply Ability: 5000000pcs per 30 days
Contact Now

M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface

Description
Product Name: M1.8x50 Air Duct Insulation Pins Galvanized Steel Material: Galvanized Steel
Brand: HUIHAO CUSTOM Head Dia: 30mm
Usage: Fasten Foil Faced Insulation Materials Pin Diameter: 1.8mm
Samples: Free Pin Length: 50mm
Highlight:

m1.8x50 welding insulation pins

,

air duct welding insulation pins

M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface
Product Specifications
Attribute Value
Product name M1.8x50 Air Duct Insulation Pins Galvanized Steel
Material Galvanized Steel
Brand HUIHAO CUSTOM
Head Dia 30mm
Usage Fasten Foil Faced Insulation Materials
Pin Diameter 1.8mm
Samples free
Pin Length 50mm
Product Description

M1.8x50 Air Duct Insulation Pins are used to fasten insulation materials onto steel duct work or other steel surfaces. The air duct insulation pins are welded to the metal after they pierce through the insulation and make contact with the surface. A Capacity Discharge Stud Welding Machine (CD) is necessary for use with these duct pins.

M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 0
Head Material: Low carbon steel
Head Surface Finish: galvanized
Head Edge: Beveled edge washer to prevent cutting of insulation material
Head Diameter (C): 30mm
Pin Material: Low carbon steel
Pin Surface Finish: galvanized
Pin Diameter (D): 1.8mm
Pin Length (L): 50mm
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 1
Technical Specifications
Item Details
Brand HUIHAO CUSTOM
Material Carbon Steel
Plating Standard is Galvanized
Copper Plating is available
Bevel Washer edge is beveled to prevent cutting of insulation material
Stainless steel Not standard, but available by special order
Head with paper Available, for welding through aluminum foil faced insulation materials
Pin with tubes Available, for welding through tin foil faced insulation materials
Head Size 1"(25mm), 1-3/16" (30mm)
Pin Diameter 1.8mm, 2.0mm, 2.7mm, 3.0mm, 3.4mm, etc.
Pin Length Custom lengths available
Package 1. 1000pcs / 2000pcs/ 3000pcs per carton
2. 48 cartons per pallet
3. Custom packaging available
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 2
Installation Guidelines
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 3
Recommended for Pin length before welding
1/2" insulation(all densities) 12.67mm
1" insulation(1-1/2"ib density) 17.63mm
1" foam 25.55mm
1"insulation(3ib densities) 23.72mm
1-1/2" insulation(all densities) 28.42mm
2"insulation(1-1/2"-2" ib density) 37.95mm
2"insulation(3ib densities) 48.77mm
3"insulation(all densities) 69.85mm
4" insulation(all densities) 95.00mm
Application Process
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 4
1. Hanging the insulation
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 5
2. Press the pin through insulation
M1.8x50 Air Duct Insulation Pins Galvanized Steel Fastening Insulation To Steel Surface 6
3. Weld in place and install the washer to complete the installation
Frequently Asked Questions
1. Are you a manufacturer or a trader?

We are a manufacturer, located in Hebei province, China.

2. Do you support product customization?

Yes, the material, the surface finish, the wire diameter, the length all could be customized.

3. Can I get samples?

Yes, samples for quality confirmation are supported in our company.

4. How do you control and ensure product quality?

1) Confirm with you every detail before quoting.
2) Before production, we will reconfirm all the details again.
3) During production, we strictly implement "IATF 16949 Quality Management System" standard.
4) We will send you videos and pictures during the production and shipment process.

5. What's your advantages?

Cooperate with us, we can ensure:
1) Competitive price: we sell what we manufacture.
2) On-time delivery: we have the auto-production line to ensure the on-time delivery.
3) Excellent quality: we have rich experience, our products are in line with international standard.
4) Good after-sale service: we offer good after-sale service for each order.
