Expanded Copper Brass Electromagnetic Shielding Mesh For Room Shielded
Product Specifications
| Attribute |
Value |
| Name |
Electromagnetic Shielding Mesh |
| Material |
Brass sheet |
| Technical |
After stamping and stretching, the metal plate processed into expanded mesh |
| Open |
1x2mm, 2x4mm, 3x6mm |
| Mesh Thickness |
0.5mm-1mm |
| Package |
Roll package |
| Manufacturer |
Huihao Hardware Mesh |
About Expanded Brass Mesh
Our expanded brass mesh is manufactured from high-quality purple copper, featuring non-magnetic properties, excellent wear resistance, superior sound insulation, and effective electron beam filtration.
Key Features
- Maximum mesh density: 2 millimeters
- Maximum mesh size: several centimeters
- Manufacturing process: Stamping and stretching
- Applications: Electronic/electromagnetic/signal shielding, wall sound insulation, electronic display screens
Available Forms
Raised Expanded Brass: Standard expanded metal with diamond openings and slightly raised surface.
Flattened Expanded Metal: Processed through a cold roll reducing mill for flat surface diamond openings.
Detailed Specifications
| Thickness |
SWG |
LWG |
STRAND |
OVER THICKNESS |
| 0.2mm |
1MM |
2MM |
1MM |
0.3MM |
| 0.3mm |
2MM |
4MM |
1.2MM |
0.4MM |
| 0.4mm |
3MM |
6MM |
1.2MM |
0.5MM |
| 0.5mm |
3MM |
6MM |
1.2MM |
0.6MM |
Product Advantages
- One-piece, single-unit construction
- Lighter weight and more economical than regular metal sheets
- Wide range of materials for various applications
- Rigid for protection while maintaining decorative effect
- High durability and long service life
- Most economical option among metal materials
- Simple and straightforward installation
About Huihao Hardware Mesh
Located in Anping County, Hebei Province - the world-renowned hometown of wire mesh - Huihao Hardware Mesh specializes in manufacturing expanded metal products including aluminum expanded metal and perforated metal.
With over 30 years of development, we maintain a complete production line for expanding, punching, cutting, and flattening, capable of producing expanded metal from 0.2mm to 10mm thickness and up to 4m width, with an annual capacity exceeding 7200 tons.
Our ISO 9001 certified facility ensures consistent quality meeting international standards, while our dedicated R&D team continuously develops solutions for diverse customer requirements.
Global Reach
Our products are exported worldwide, including to the UK, Norway, Netherlands, Cyprus, USA, Canada, Mexico, Ecuador, Brazil, South Africa, Indonesia, and India, with hundreds of satisfied customers maintaining long-term business relationships.
Why Choose Huihao Hardware Mesh?
| The Most Professional |
- Established factory since 1998
- Highly skilled workforce
- Sophisticated manufacturing equipment
|
| Professional Sales Team |
- Over 10 years international export experience
- Proficient in products and international business
- Excellent teamwork
|
| Quality Control |
- ISO9001:2015, ISO14001:2004 certified
- Strict factory inspection standards
- Premium quality raw materials
|
| Payment Options |
- T/T
- L/C
- D/P
- OA
- Trade assurance
|
| Delivery Time |
- Immediate material procurement after order
- Scientific process control
- Prompt container loading
- Optimal shipping arrangements
|
| Customer Service |
- Payment confirmation
- Regular order progress updates
- Production photos
- Loading documentation
- Comprehensive after-sales follow-up
|
