Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps

Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps
Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps

Large Image :  Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps

Product Details:
Place of Origin: China
Brand Name: HUIHAOCUSTOM
Certification: ISO9001-2015
Model Number: SKD-11
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: 120000 usd
Packaging Details: Stretch film and wooden case as international sea shipment standards for PET recycling machine
Delivery Time: 10 work days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per 28 days

Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps

Description
NAME: Plastic Washing Line
High Light:

car battery plastic recycling line

,

abs plastic recycling line

,

car battery plastic recycling production line

Environment Protection Car Battery Recycling Machine PE PP ABS PC PS Plastic Washing Line

Plastic (Film/woven bag/fiber/rope) Washing Line has smart modular design aiming at agricultural film, industrial packaging film, bag waste recycling. It is including sorting, size reduction, metal removing, cold and hot washing, high efficiency friction washing and drying modular. Which can remove most of contaminants such as ferrous and nonferrous metals contaminants efficiently. Moreover, the solution can be provided with all water treatment, processing of sludge, paper stick, labels and etc.



Technical data of PE PP ABS PC PS Plastic Washing Line

Name
Motor power (kw)
Dimension (mm)
Water consumption (T/H)
Stainless steel standard (mm)
Electric standard
Belt conveyer
2.2



3500*900*3000
-
-
According to customers standard
Label Scraping Machine
11
2600*1200*1800
0.6-1.0
3-5
Manual separating Machine
2.2
6000*800*1200
-
-
Metal detectory
0.4
2200*1200*1500
-
3-5
Belt conveyer
2.2
3500*900*3000
-
-
Crusher
37
2200*2200*3000
0.6-1.0
-
Screw conveyer
3
2800*800*2600
-
3-5
High speed friction washer
30
3200*1400*2000
1-2
3-5
screw conveyer
3
2800*800*2600
-
3-5
floating washer
3*2
5200*1700*2200
0.5-1.5
3-5
screw conveyer
3
2800*800*2600
-
3-5
Steam Washer
7.5
1800*1800*2700
0.5-1.5
3-5
Screw Conveyer
3
2800*800*2600
-
3-5
Floating washer
3*2
5200*1700*2200
0.5-1.5
3-5
Screw conveyer
3
2800*800*2600
-
3-5
dewatering machine
5.5
800*2200*2200
-
5
drying system
11
3500*2200*2200
-
3-5
Label separater
4
800*1100*3800
-
-
storage hopper
-
1500*1500*3800
-
-
electric elements
-
2000*450*1780





Equipment details of PE PP ABS PC PS Plastic Washing Line

Crusher
  • rotor with balance treatment for stability and low noise
  • rotor with heat treatment for long lifespan
  • wet crushing with water, which can cool the blades and wash the plastic in advance
  • can also choose shredder before the crusher
  • special rotor structure design for different plastics like bottles or film
  • blades made of special material, with high hardness
  • easy operation to change blades or screen mesh
  • high capacity with stability
Screw conveyor
  • Conveying plastic materials
  • Made of SUS 304
  • With water input to rub and wash the plastic scraps
  • with 6mm vane thickness
  • made by two layers, dewatering screw type
  • hard tooth gear box which ensures long lifespan
  • special bearing structure to protect bearing from possible water leakage
Floating washer
  • rinse the pieces of flakes or scraps in water
  • can use hot type washer to add chemical for washing
  • upper roller be inverter controlled
  • all tank made of SUS304 or even 316L if needed
  • bottom screw can process sludge
Friction Washing
  • Friction to clean the materials mechanically
  • rotor made of strong&thick material, surface treatment with alloy
  • rotor with balance treatment for stability
  • rotor with heat treatment for long lifespan
  • The bearing is externally connected with water cooling sleeve, which can effectively cool the bearing.
Dewatering Machine
  • Drying materials by centrifugal force
  • rotor made of strong&thick material, surface treatment with alloy
  • rotor with balance treatment for stability
  • rotor with heat treatment for long lifespan
  • The bearing is externally connected with water cooling sleeve, which can effectively cool the bearing.

Floating Washing Tank

  • Function: Floating Washing separate the sand, soil and other dirty.
  • The roller is specially made can have more washing for lakes but less water take out.
  • Bottom with Positive and negative screw to push the dirty into middle.

Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps 0Environment Protection Car Battery Plastic Recycling Line For Pe Pp Abs Pc Ps 1
