Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine

Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine
Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine

Large Image :  Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine

Product Details:
Place of Origin: China
Brand Name: HUIHAOCUSTOM
Certification: ISO9001-2015
Model Number: HT-2000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD85000
Packaging Details: Stretch film and wooden case as international sea shipment standards for plastic recycling machine
Delivery Time: 8 work days
Payment Terms: L/C, T/T
Supply Ability: 100 SETS PER 30 DAYS

Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine

Description
Name: Recycling Crushing Washing Drying Machine Line Application: PET Bottle Washing Machine
Max.Production Capacity (kg/h): 5000 Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel
Water Supply: 2-3 CBM Per Hour Used For: Pet Bottle Flakes Drying
Final Pet Flakes: Less Than 1% Control: Electric Control
Weight (T): 10 Final Product: Clean PET Bottle Flakes
High Light:

2000kg/hr plastic recycling line

,

pet bottles crushing plastic recycling line

,

2000kg/hr pet bottle recycling machine

2000kg/Hr Waste Plastic PET Bottles Recycling Crushing Washing Drying Machine Line

Huihaocustom series Efficient plastic recycling machine is mainly used to recycling the waste PET bottles, water bottles,cola bottles, PET sheet and PET packing containers. The Recycled waste cola bottle PET recycling machine can easily remove the labels, caps, rings, glue, dirties and other impurities, finally you will get ideal PET flakes. All your requirements of the Recycled waste cola bottle PET recycling machine will be customized.



Technical data of PET Bottles Recycling Crushing Washing Drying Machine Line

We have 500-5000 kg/h MT Series Efficient plastic recycling machine.and We can design the layout according to your requirements .
Model
Capacity
Installed Power
Steam Use
Water Supply
Manpower
Area Required
HT-500
500 kg/hr
190 KW
Optional
4-5 m3/hr
4-6 Person
60*5*5 m
HT-1000
1000 kg/hr
260 KW
Optional
6-8 m3/hr
8-10 Person
80*8*5 m
HT-2000
2000 kg/hr
400 KW
Suggest Use
10-15 m3/hr
10-12 Person
80*8*5 m
HT-3000
3000 kg/hr
600 KW
80,000 Kcal
20-30 m3/hr
12-16 Person
100*8*10 m
HT-4000
4000 kg/hr
800 KW
100,000 Kcal
30-40 m3/hr
15-20 Person
135*10*10 m
HT-5000
5000 kg/hr
1000 KW
120,000 Kcal
40-50 m3/hr
15-20 Person
135*10*10 m



Functions of PET Bottles Recycling Crushing Washing Drying Machine Line

De-Baling Machine

Function: Opening the PET bottle bales
With 4 roller cylinder to feeding the bottles equally. Claw steel is very strong and the thickness is 20mm.

Machine chamber made by solid strong steel. Working chamber size can above 1600x1600mm(depth x width).
Machine fixed with support over the sorting table
Label Remover Machine
Function:remove the labels from the bottle and separate label out from bottles.
Blade made by alloyed steel for long time use.
Blade is fixed by screw on the rotor easy to adjustable and changeable.
The barrel is designed with doors opening on it very easy to opening and maintenance .
The machine bottom with holes to drain out liquid which contained in the bottles, good for machine use.
Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine 0

Label Remover Machine

Function:remove the labels from the bottle and separate label out from bottles.
Blade made by alloyed steel for long time use.
Blade is fixed by screw on the rotor easy to adjustable and changeable.
The barrel is designed with doors opening on it very easy to opening and maintenance .
The machine bottom with holes to drain out liquid which contained in the bottles, good for machine use.
Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine 1

Plastic Crusher Machine

Function: crushing the bottles to PET flakes.

With water inlet do wet crushing. Chamber opened by screw motor.
Specially designed PET bottle Crusher Machine can easily get high output and with water doing wet grinding can extension the blades use life, reduce the dust generation.
Bearing house is outside of the crusher chamber so no dirty goes inside for longer use.
Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine 2

Hot Washing Tank

Function: with hot water washing to remove oil/glue and other dirty from the flakes.
The tank made with insulation layer to save energy.
Feeding caustic soda/detergent to washing Its better Heating by steam,
You can buy a steam boiler to produce the steam.
The boiler can heating up by gas/diesel/petrol/LPG
Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine 3

Final "Zig-zag" Label Separator

Function: Remove the final labels, dust and other mini material from the flakes to guarantee the PVC content.
Blower can be adjusted by inverter.
With inverter to control the air flux of blower.
Zig zag main chamber one set made by stainless steel.
Chamber with plexiglass window to open and check inside
Waste 2000kg/Hr Plastic Recycling Line Pet Bottles Crushing Washing Drying Machine 4
