Product Details:
|
| Name: | Plastic Recycling Line Plastic Crusher Machine | Plastic Type: | PVC, PET, ABS, PP/PE, PE, PP, PC, PMMA, PA, PS |
|---|---|---|---|
| Machine Type: | Plastic Crusher | Voltage: | Customized |
| Power (kW): | 37 | Production Capacity (kg/h): | 300 - 2000kg/h |
| Motor: | SIMENS | Life Time: | 10 Years |
| High Light: | 37KW PMMA Plastic Recycling Line,PET P Plastic Recycling Line,2000kg/H Plastic Crusher Machine |
||
Used for tcrushing the PET bottle, Plastic bottle, buckets, hollow containers, and so on plastic; Its with special structure design, will have more capacity with less power consumption
1. Plastic crusher machine Frame is made by solid square tube steel.
2. Shaft is made by 45# steel with quenching treatment.
3. Chamber is made by solid steel 40mm thickness.
4. Screen mesh is made by 10mm thick steel for durable use.
5. Plastic crusher machine own Easy-disassembling design, chamber is opened by motor automatically, which is simple and labor-saving to clean and maintain,and also convenient to change the blades.
6. Bearing house installed outside of the crusher chamber so no dirty goes inside which prolong the lifespan.
7. Plastic crusher Machine upside chamber is higher and covered by belt no flakes popped out.
8. Blades are made by famous brand SKD-II from Japan with top quality
9. Plastic crusher machine Special designed cross-type cutter structure ensure high capacity and low power consumption.
| Model | S-600 | S-800 | S-1000 | S-1200 | S-1500 |
| Rotor Blades | 8 | 8 | 8 | 8 | 8 |
| Fixed Blades | 4 | 4 | 4 | 4 | 4 |
| Screen | 14/16 mm | 14/16 mm | 14/16 mm | 14/16 mm | 14/16 mm |
| Power | 30 KW | 37/45 KW | 45/55 KW | 55/75 KW | 75/90 KW |
| Capacity | 300 kg/h | 500 kg/h | 800-1000 kg/h | 1000-1500 kg/h | 1500-2000 kg/h |
| Crusher screen: Mesh diameter:14mm, Mesh thickness:10mm | Motor: Make the motor performance good and can be used for a long time. |
| Fixed blade: the blades more wider can sharpening 20-25 times , it will save the blade cost. Mateial: 9Crsi/SKD-11/D2 | Rotor: With strong rotor made and shaft
Shaft made by 45#steel with quenching treatment
|
