35mm Dia Powder Actuated Washered Pin For EPS Insulation Boards

Large Image : 35mm Dia Powder Actuated Washered Pin For EPS Insulation Boards

Product Details:

Place of Origin:	CHINA
Brand Name:	HUIHAO
Certification:	ISO9001
Model Number:	Powder Actuated Washered Pin

Payment & Shipping Terms:

Minimum Order Quantity:	5000 pcs
Packaging Details:	1.500pcs/1000pcs/5000pcs per carton 2. on pallet
Delivery Time:	7-10 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	100000 per week

Contact Now

35mm Dia Powder Actuated Washered Pin For EPS Insulation Boards

Description

Name:	Powder Actuated Washered Pin	Type:	Soft Washer
Material:	PE Colors	Diameter:	35mm
Color:	Grey ,white	Sample:	Available
Service:	Door To Door Service	Usage:	EPS Insulation Boards
Highlight:	35mm Powder Actuated Washered Pin , EPS Insulation Boards 35mm Pin , EPS powder actuated washered pin

35mm Dia Powder Actuated Washered Pin For EPS Insulation Boards

Product Specifications

Attribute	Value
Name	Powder Actuated Washered Pin
Type	soft washer
Material	PE colors
Diameter	35mm
Color	grey, white
Sample	available
Service	door to door service
Usage	EPS Insulation Boards

Product Details

Product name: 35mm powder actuated washered pin, drive pin with plastic washers

Pin Material: The drive pin material can be carbon steel, stainless steel material

Pin shape: 0.145" in common

Pin head diameter: 0.300"

Pin length: to be requested

Washer size: 35mm

Color: white, grey in common

The drive pin with plastic washer can be widely used in floor heating industry, power plants, petrochemical external wall insulation engineering, architectural wall reinforcement, noise, the construction industry, drill diameter 8 or 10. Available in different lengths fitting to the thickness of insulation board. We can make all kinds of plugs according to buyers' demands.

35mm Powder Actuated Washered Pin

35mm Plastic Clip Drive Pin In Carbon Steel Material Suit P370 Or P200 Tools

Compatible Tools: PTP-27L, PT-27, PT-22A, PT-22HA

Color: White

Manufacturer Part #: PINWP-250W

Head Diameter: .300"

Measurement Type: Inch

Shank Diameter: 0.145"

Shank Length: 2-1/2"

Shank Style: Smooth Style: Powder-Actuated Plastic-Washered Pin

Product Images

Technical Specifications

washer material	PE
washer size	35mm
washer height	15mm
Tube diameter	6mm
Color	grey, white
Drive pin material	galvanized steel or stainless steel
Pin head	0.300" in common
Pin shank	0.145"
Pin length	to be requested
Usage	attaching steel to concrete, block or steel

Packaging & Delivery

Package of 36mm metal washer:

500 pcs per bag, 10 bags per carton. 64 cartons per pallet.
Can be customized to your requirements.

Delivery Options:

Sample: DHL/EMS/UPS/TNT/EXPRESS
Large Order: we recommend by SEA, or by AIR if in an emergency

Frequently Asked Questions

Q1: Are you factory or trader?

Yes, we sell what we manufacture.

Q2: How long is your delivery time?

Usually the ship time is within 7-15 days.

Q3: What is your quote elements?

The size of product, material with surface treatment and the quantity.

Q4: Can you provide samples? Is it free or in charge?

Yes, we can provide sample for we have in stock. For special sample you need pay the mold fee, the mold fee will return back you after confirm the mass order.

Q5: How can you ensure the quality?

We can supply CAD drawing pic for you
Our company have ISO certificate
We have working on this product for twenty years and we have experience on it, and we know the point you focus on

About HUIHAO Company

HUIHAO company is a insulation fasteners/insulation anchors manufacturing company. We produce all kinds of insulation pins and washers, and can make mold according to your drawing pic. Our products include:

CD weld pins Lacing Anchors
bimetallic pin Cup head weld pins
Quilting pins perforated base pins
self adhesive pins aluminum solar panel mesh clip
all kinds of self locking washers, Dome caps
