Customized Length Metal Peel & Press Steel Pins with washer

Customized Length Metal Peel & Press Steel Pins with washer
Customized Length Metal Peel & Press Steel Pins with washer Customized Length Metal Peel & Press Steel Pins with washer Customized Length Metal Peel & Press Steel Pins with washer

Large Image :  Customized Length Metal Peel & Press Steel Pins with washer

Product Details:
Place of Origin: China
Brand Name: HUIHAO CUSTOM
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 10,000sets
Price: USD0.03-0.25/set
Packaging Details: Carton and pallets
Delivery Time: 8-20 work days
Payment Terms: L/C,T/T
Supply Ability: 500,000 sets per week

Customized Length Metal Peel & Press Steel Pins with washer

Description
Product Name: Peel & Press Steel Pins Material: Galvanized Steel , Stainless Steel , Aluminum
Base Size: 50X50mm Pin Lenght: 3/4'' -12'', Custom Length
Pin Diameter: 2.7mm Washer Size: 25mm,30mm,38mm 50mm In Common
Pakcing: 500 Sets In One Box Or As Request . Sample: SUPPORT
Highlight:

Washer Steel Pins

,

Customized Length Steel Pins

Customized Length Metal Peel & Press Steel Pins with Washer
Product Overview

Peel & Press Steel Pins provide secure, easy-to-install insulation pinning for residential and commercial duct insulation and HVAC systems. Available in multiple lengths and washer sizes for versatile applications.

Key Specifications
Product Name Peel & Press Steel Pins (Self Adhesive Insulation Pins)
Material Galvanized Steel, Stainless Steel, Aluminum
Base Size 50×50mm
Pin Length 3/4" to 12" (Custom Length Available)
Pin Diameter 2.7mm (3.0mm Available, Customizable)
Washer Size 25mm, 30mm, 38mm, 50mm (17mm-70mm Customizable)
Adhesive Thickness 1mm
Packaging 500 sets per box or custom packaging available
Customized Length Metal Peel & Press Steel Pins with washer 0 Customized Length Metal Peel & Press Steel Pins with washer 1
Product Features
  • Self-attaching design requires no additional tools
  • Available in multiple materials for different applications
  • Customizable pin lengths and washer sizes
  • Square, round, and dome cap washer options
  • Easy installation process
  • Superior insulation performance
Applications

Our self-adhesive insulation pins are widely used for:

  • HVAC system insulation
  • Duct insulation
  • Electrical insulation
  • Soundproofing applications
  • Thermal insulation projects
  • Attachment of insulation material to metal surfaces
Installation Guide
1. Clean the installation surface
2. Peel off the adhesive backing
3. Position and stick the pin in place
4. Apply pressure to secure the pin
5. Wait 15-20 minutes for adhesive to set
6. Install insulation and secure with self-locking washer
Customized Length Metal Peel & Press Steel Pins with washer 2 Customized Length Metal Peel & Press Steel Pins with washer 3 Customized Length Metal Peel & Press Steel Pins with washer 4
Packaging & Shipping

Small orders: Packed in boxes and shipped by express

Large orders: Packed with cartons and pallets, shipped by air or sea

Contact Information

For pricing inquiries or sample requests, please contact us at david@huihaomesh.com

OEM support available for custom requirements
