Product Details:
|
Product Name: | Metal Coil Drapery | Material: | Aluminum Alloy |
---|---|---|---|
Surface Treatment: | Anodizing, Spraying, Pvdf | Color: | Copper, Brass, Grey |
Wire Diamter: | 1mm, 1.2mm,1.5mm | Width: | Less Than 6000mm |
High Light: | coil mesh drapery,metal coil curtain |
Metal Coil Drapery,Wire Mesh Curtains is also called metal coil drapery. Generally, it is made from stainless steel wire,
aluminum wire, copper wire or other materials. It is a new kind of high end metal curtain like chain link curtain and chain
mail curtain that used to decorative office buildings, hotels, shopping center, concert halls and other places.
Specifications of Metal Coil Drapery,Wire Mesh Curtains
Surface treatment: pickling, anodic oxidation, baking varnish or spray coated.
Color: silver, golden, brass yellow, black, gray, bronze, red, original metallic color or spray into other colors.
Wire diameter: 0.5 mm - 2 mm.
Aperture size: 3 mm - 20 mm.
Open area: 40% - 85%.
Thickness: 5.5 mm - 7.1 mm.
Weight: 4.2 kg/m2 - 6 kg/m2. (depending on material and size chosen)
Terms |
Diameter (mm) |
Aperture (mm) |
Thickness (mm) |
---|---|---|---|
hhmesh-1 |
0.8 | 4 | 3.6 |
hhmesh-2 |
0.8 | 5 | 3.6 |
hhmesh-3 |
0.8 | 6 | 3.6 |
hhmesh-4 |
0.8 | 8 | 3.6 |
hhmesh-5 |
0.8 | 9 | 3.6 |
hhmesh-6 |
1.0 | 4 | 3.6 |
hhmesh-7 |
1.0 | 5 | 3.6 |
hhmesh-8 |
1.0 | 6 | 3.6 |
hhmesh-9 |
1.0 | 8 | 3.6 |
hhmesh-10 |
1.0 | 9 | 3.6 |
hhmesh-11 |
1.0 | 10 | 3.6 |
hhmesh-12 |
1.0 | 20 | 3.6 |
hhmesh-13 |
1.2 | 4 | 3.6 |
hhmesh-14 |
1.2 | 5 | 3.6 |
hhmesh-15 |
1.2 | 6 | 3.6 |
hhmesh-16 |
1.2 | 8 | 3.6 |
hhmesh-17 |
1.2 | 9 | 3.6 |
hhmesh-18 |
1.2 | 10 | 3.6 |
hhmesh-19 |
1.2 | 20 | 3.6 |
hhmesh-20 |
1.2 | 30 | 3.6 |
Applications of Metal Coil Drapery,Wire Mesh Curtains
According to its different applications, metal coil drapery can be used in many architecture design and building decoration.
So metal coil curtain can be used as:
Interior partition.Door curtain.Security gate.Shower curtain.Sun shades.Store fixtures.Ventilation grilles.Privacy ceiling panels.
Fireplace mesh curtain.Interior space curtains.Decorative facade fabric.Architecture outside designs.Exterior wall cladding
material.Wall decoration.Blast debris protection.Sound insulation.Day-lighting screening.Fall protection.
Installations of Metal Coil Drapery,Wire Mesh Curtains-About the installations of metal coil drapery, we have three methods.
U track installation, H track installation and stainless steel curtain rod installation.
|
||
U track and H track are made from anodized aluminum material. Both are lightweight and rust resistance. These three curtain
tracks all have strong steel support, free flowing gliders that can withstand all weights of curtains.
