Product Details:
|
| Name: | Stainless Steel Bi-metallic CD Studs With Aluminum Weld Base | Application: | Used For Marine Industry |
|---|---|---|---|
| Base Material: | Aluminum Alloy | Base Size: | 6x15mm |
| Pin Material: | Stainless Steel | Pin Size: | 3mm X65mm |
| Install Parts: | Self Locking Washers | Sample: | Free For Size In Stock |
| High Light: | aluminum weld base cd studs,marine industry cd studs |
||
The stainless steel Bi-Metallic CD Studs with aluminum weld base are widely used in ship pipeline
insulation welding, ship plate fixing, air conditioning and ventilation pipeline insulation welding,
offshore oil platform insulation welding and other industries
|
Name: Stainless Steel Bi-metallic CD Studs With Aluminum Base For Marine Industry Factory: Huihao Hardware Mesh Product Limited. Base Material: Aluminum Alloy 5000 Series Base Size: 6mmx15mm Flange Width: 8mm Nail Material: Stainless Steel Nail Diameter: 3mm Nail Length: As your requirement
|
 |
The Bi-Metallic CD Stud is consists of a nail and an aluminum base.
The nail is processed from low carbon steel or stainless steel, and then the surface is galvanized
or polished. It is used together with a dome cap washer or a metal speed clip.
Name: Bi-metallic CD Studs
Factory: Hebei Xiangyi Metal Product Co.,Ltd.
Base Material: Aluminum Alloy 5000 Series
Base Size: 6mmx15mm
Flange Width: 8mm
Nail Material: Stainless Steel or Copper Coated Steel
Nail Diameter: 3mm, 4mm, 5mm, 6mm
Nail Length: 25-300mm
Washers diameter:32mm,38mm etc
The below size is most popular in market. other sizes can be make too.
| Base Material | Pin Material | Diameter | Length |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 50mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 65mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 70mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 75mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 80mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 85mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 90mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 100mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 110mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 125mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 130mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 150mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 160mm |
| 5000 Series Aluminum | Stainless steel/copper coated mild steel | 3, 4, 5, 6mm | 180mm |
1. high welding quality
2. easy to weld
3. quick mounting
4. installable in all positions
5. fire-resistant
|
1. 100 pcs, 200 pcs, 300pcs, 500 pcs in one plastic bag (according to the pin length ), 2. 10 bags in one carton box, 3. then in one pallet 4. the package can be can according to your request |
|
|
