M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs

M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs
M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs

Large Image :  M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs

Product Details:
Place of Origin: China
Brand Name: Huihao
Certification: ISO9001:2008
Model Number: Anchor Wall Plugs
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Packaging Details: paper carton + wood pallet
Delivery Time: 12days after first payment
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 500000 pcs per 15 days

M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs

Description
Name: Anchor Wall Plugs Material: PP, PE, Nylon, Steel
Pin Dia: M8-M12 Pin Length: As Request
Washer Size: 50mm,60mm In Common Small Order: Available
High Light:

rockwool insulation pins

,

duct insulation pins



M8X90mm Plastic insulation Fixing Anchors , PE Material Anchors Wall plugs



Insulation fixing anchors is a special engineering plastic expansion wall plugs that fixes the insulation board to the wall. Insulation fixing anchors

are special anchors for exterior wall insulation, which are widely used in building decoration and anchoring of wall insulation houses. It consists

of galvanized screws, nylon risers and fixed discs. According to the thickness of the insulation layer, it is divided into various specifications.



Material: It is made of the nylon material, durable and well designed for holding items firmly on the wall.The head of the screw is

countersunk head.The screw is steel made and yellow zinc plated.The length of the screw is standard.The plug is made of the gray nylon.

  • Structure: Geometry of the expansion pipe, in the solid structure of the object in the expansion.

  • Color:Most grey and white, other colors are also available.

  • Function: To prevent rotation of the structral design, when using the screw does not rotate in the air to follow.

  • Feature:Elasticity, shock resisting, durable, light weight, easy installation, resistance to corrosion

 types of plastic insulation fixing anchor/anchor wall plugs



Conjoined: 8×62, 8×82, 8×102, 8×122, 8×142, 10×162.
Split: 10×162, 10×182, 10×202, 10×252, 10×302, 10×352, 10×402, 10×452, 10×502, 10×552, 10×602



Anchors wall plugs data sheet



Pin Size Pin Dia Pin Length Washer dia Packaging
M8x50 8mm 50mm 45mm-60mm,could be customized 1000pcs / carton
M8x60 8mm 60mm 45mm-60mm,could be customized 1000pcs / carton
M8x90 8mm 90mm 45mm-60mm,could be customized 1000pcs / carton
M8x110 8mm 110mm 45mm-60mm,could be customized 1000pcs / carton
M8x140 8mm 140mm 45mm-60mm,could be customized 1000pcs / carton
M10x160 8mm 160mm 45mm-60mm,could be customized 1000pcs / carton
M10x190 8mm 190mm 45mm-60mm,could be customized 1000pcs / carton



Performance parameter of plastic insulation fixing anchor/anchor wall plug


According to the JG/T366-2012 standard;
Knocking anchor: Tap the expansion joint or expansion sleeve to squeeze the borehole wall to create an expansion anchor.


Claim:
1. The nominal diameter of the disk of the disc anchor should not be less than 60mm and the tolerance is 1.0mm. The nominal

diameter of the expansion sleeve should not be less than 8 mm with a tolerance of ±0.5 mm.
2. Standard value of anchorage capacity of anchor bolt: standard value of tensile load capacity of anchor bolt Fk≥0.60
3. Anchor bolt disc tensile force standard value: disc pullout standard value Frk≥0.50



M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs 0



Fixing steps of the Plastic fixing anchors

First, we need to use electric drill to drill specific size of the hole
Second, putting expand plug in the hole
Finally, using a screwdriver to tighten screw into the expansion tube until the specified location



The arrangement of the external anchor wall plug. The number of anchors installed on the outer wall insulation system of the extruded board;

the average of 1-10 layers is 6/m2, the average of 11-20 layers is 7/m2, and the layers of 21-26 are 9/m2. Any single block with an area greater

than 0.1m2 must be anchored, depending on the shape and site conditions;

the density of the anchor should be increased around the angle of the sun, under the mouth, and around the edge of the hole.

The distance is not more than 300mm, from the edge of the base. Not less than 60mm



M8X90mm Plastic Insulation Fixing Pins , Insulation Wall plugs 1
