Product Details:
|
| Name: | British Hose Clamp | Material: | Stainless Steel 304/ Galvanized Steel |
|---|---|---|---|
| Brand Size: | 9.7/11.7mm | Usage: | Pipe Clamp |
| Clamping Range: | 8-14/277-307mm | Finished: | Zinc Plated |
| High Light: | rockwool insulation pins,duct insulation pins |
||
specification of British Hose Clamp Wth Tube Housing, Insulation Metal Clamping Band Hose Clips
| clamp range mm | brand width mm | pcs/bag | pcs/carton | suggested installtorque |
| 8-14 | 9.7 | 100 | 2000 | 3.0Nm |
| 11-17 | 9.7 | 100 | 2000 | 3.0Nm |
| 13-20 | 9.7 | 100 | 2000 | 3.0Nm |
| 15-24 | 9.7 | 100 | 2000 | 3.0Nm |
| 18-28 | 9.7 | 100 | 2000 | 3.0Nm |
| 22-32 | 9.7 | 50 | 1000 | 3.0Nm |
| 26-38 | 9.7 | 50 | 500 | 3.0Nm |
| 32-44 | 9.7 | 50 | 500 | 3.0Nm |
| 38-50 | 9.7 | 50 | 500 | 3.0Nm |
| 44-56 | 9.7 | 25 | 500 | 3.0Nm |
| 50-65 | 9.7 | 25 | 250 | 3.0Nm |
| 58-75 | 9.7 | 25 | 250 | 3.0Nm |
| 68-85 | 9.7 | 10 | 250 | 3.0Nm |
| 77-95 | 9.7 | 10 | 250 | 3.0Nm |
| 15--24 | 11.7 | 50 | 500 | 4.8Nm |
| 19--28 | 11.7 | 50 | 500 | 4.8Nm |
| 22--32 | 11.7 | 50 | 500 | 4.8Nm |
| 26--38 | 11.7 | 50 | 500 | 4.8Nm |
| 32--44 | 11.7 | 50 | 500 | 5.2Nm |
| 38--50 | 11.7 | 50 | 500 | 5.2Nm |
| 44--56 | 11.7 | 25 | 500 | 5.2Nm |
| 50--65 | 11.7 | 25 | 500 | 5.2Nm |
| 58--75 | 11.7 | 25 | 200 | 5.2Nm |
| 68--85 | 11.7 | 25 | 200 | 5.2Nm |
| 77--95 | 11.7 | 10 | 200 | 5.2Nm |
| 87--112 | 11.7 | 10 | 200 | 5.2Nm |
| 104--138 | 11.7 | 10 | 100 | 5.2Nm |
| 130--165 | 11.7 | - | 100 | 5.2Nm |
| 150--180 | 11.7 | - | 100 | 5.2Nm |
| 175--205 | 11.7 | - | 100 | 5.2Nm |
| 200--231 | 11.7 | - | 50 | 5.2Nm |
| 226--256 | 11.7 | - | 50 | 5.2Nm |
| 251--282 | 11.7 | - | 50 | 5.2Nm |
| 277--307 | 11.7 | - | 50 | 5.2Nm |
details of British Hose Clamp Wth Tube Housing, Insulation Metal Clamping Band Hose Clips
Surface treatment difference:
Galvanizing treatment: (blue white zinc, multicolored zinc, military green, brown, black, etc.); The corrosion resistance is 48-96 hours
Zinc aluminum coating: (Dacromet, Jiumei, Meili, etc.); The corrosion resistance is 120-1080 hours.
Metal coating: (Zn-Ni alloy, gold plating, silver plating, copper plating, etc.); The corrosion resistance is 240-720 hours.
British Hose Clamp Wth Tube Housing is widely used in various fields such as automobile oil circuits, engine pipelines, drainage pipelines,
building materials, hardware, etc.
