3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer

3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer

    • 3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer
    • 3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer
    • 3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer
  • 3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer

    Product Details:

    Place of Origin: China
    Brand Name: huihao
    Certification: ISO9001-2015
    Model Number: mixing-dryer

    Payment & Shipping Terms:

    Packaging Details: containers
    Delivery Time: 7 work days
    Payment Terms: L/C, T/T
    Supply Ability: 30 sets per month
    Contact Now
    Detailed Product Description
    Name: Mixing-dryer The Motor Power: 7.5w
    Speed: 350r/min Capacity: 3000kgs



    Cheapest Machine 3000 kgs Vertical Mixing Dryer For Plastic Particles



    Specification of Cheapest Machine 3000 kgs Vertical Mixing Dryer For Plastic Particles



    Model

    HH--500

    HH--1000

    HH--2000

    HH--3000

    HH--5000

    Capacting(KG)

    500

    1000

    2000

    3000

    5000

    The motor power(KW)

    3

    4

    5.5

    7.5

    11

    Heating power(KW)

    12

    20

    30

    40

    50

    Speed(r/min)

    350

    Overall dimensions(CM)

    120*120*235

    160*160*265

    175*175*355

    220*220*385

    240*240*435



    We can design different plastic washing line according to your requirements:

    • Equipment name: PET plastic recycling equipment.
    • Production capacity: 500kg/h,1000kg/h 1500kg/h,2000kg/h,3000kg/h.
    • Material processed: PET bottle (such coca-cola ,small oil drum etc )
    • You can choose different devices according to your material. You can also purchase separate device based on your own conditions.
    • We providing turn-key project for you. Design-Product-Installment-Testing.
    • Superiority: Easy operation, high capacity, low energy consumption, safety, reliability, etc.

    Plastic mixing dryer advantages:

    the hot air from the barrel at the bottom side of the traditional drying machine to enter, because raw material is static, so the hot air difficult

    to penetrate, making dryer internal appear the phenomenon of lower heat the upper temperature, sometimes by local overheating of

    sintering raw material, cause jams, to make it more difficult to enter other areas, hot air dry reason cannot reach the expected effect. The

    design of the machine is two-stage screw slurry conveying, the first stage carries the raw materials into the barrel, the second stage lifts

    the raw materials to the upper part of the barrel to scatter in an umbrella shape, and the hot air blows out from the center of the lower part

    of the barrel to the four sides, so that the raw materials can be heated fully in the dynamic condition. Make plastic dryer series beautiful and

    strong, temperature control, greatly improve the drying efficiency, complete machine types, there are general and dehumidification type,

    widely won the trust and love of the plastic industry at home and abroad, is the modern plastic molding plant indispensable equipment.



    3000 Kgs Vertical Dryer Plastic Mixer Machine , Ss Plastic Granule Mixer
