Anti-Clogging Quarry Steel Screen Mesh For Stone Crusher

Large Image : Anti-Clogging Quarry Steel Screen Mesh For Stone Crusher

Product Details:

Place of Origin:	China
Brand Name:	huihaokasite
Certification:	ISO9001-2015
Model Number:	Quarry Steel Screen Mesh

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	USD56-USD188/PC
Packaging Details:	1. 20 pieces per wooden pallets. 2.25pallets per 20ft container 3. to be your requesr.
Delivery Time:	5-8 work days
Payment Terms:	L/C,T/T,Western Union,payoal
Supply Ability:	3000 PCS PER 25 DAYS

Contact Now

Anti-Clogging Quarry Steel Screen Mesh For Stone Crusher

Description

Name:	Quarry Steel Screen Mesh	Material:	65MN STEEL
Wire Diameter:	0.5-5mm	Screen Mesh Width:	Less Than 2800 Mm
Length Of Screen Mesh:	Requirements	Stand Material:	Pu
Highlight:	crimped wire mesh , stainless steel filter mesh

Anti-Clogging Quarry Steel Screen Mesh For Stone Crusher

Product Specifications

Attribute	Value
Name	Quarry Steel Screen Mesh
Material	65MN STEEL
Wire diameter	0.5-5mm
Screen mesh width	less than 2800 mm
Length of screen mesh	Custom requirements
Stand material	PU

Product Description

We manufacture Stone Crusher Anti-Clogging Separator Mesh/65MN Doser Harp Self Cleaning Screen with the following specifications:

Mesh Types: Square Mesh, Rectangular Slotted Mesh, Elongated Mesh
Crimp Types: Flat Top, Double Crimp, Lock Crimp, Corrugated Crimp

Key Features

Materials: Manganese steel wire, mild steel wire, stainless steel wire
Weaving patterns: Crimped before weaving, double crimped, single crimped
Features: Wear and abrasion resistant, heavy impact resistant, long service life, high strength

Technical Specifications

Aperture (mm)	Wire diameter (mm)	kg/m²	Screening area %
1.50	1.20-1.60	4.7-6.8	31-38
2.00	1.20-1.60	4.3-6.2	37-43
3.00	1.20-2.00	3.6-7.8	40-52
4.00	1.20-2.00	3.1-6.9	45-58
5.00	1.50-2.80	2.7-11	41-65
6.00	1.50-2.80	3.4-9	48-64
8.00	2.00-3.15	4.5-9.1	53-63
10.00	2.00-3.15	3.7-8.0	59-69
14.00	2.00-4.00	3.0-9.6	61-76
19.00	2.80-4.00	4.2-7.9	68-76
22.00	2.50-4.00	3.0-7.1	72-80
25.00	4.00-5.00	6.4-9.3	70-74
26.00	4.00-5.00	6.10-9.20	70-75
28.00	3.00-4.00	3.5-5.8	77-82
30.00	3.00-4.00	3.3-5.6	78-83
32.00	4.00	5.30	79
35.00	4.00-5.00	4.8-7.3	77-81
40.00	4.00	4.00	84

Available Variants

Crimped square wire mesh
Standard square wire mesh
Square wire mesh, hot-dipped (electro) galvanized after weaving
Square wire mesh, hot-dipped (electro) galvanized before weaving
Iron wire mesh

Applications

Used in mines and coal industry for sieving stone and sand
Stainless steel variants for decoration and fencing (corrosion and heat resistant)
Galvanized screens for food roasting applications
Custom sizes available per customer requirements (mesh opening, width, length)

Packaging Details

20 pieces per wooden pallet
25 pallets per 20ft container
Custom packaging available per request
