Stainless Steel Partial Thread ARC Welding Studs With A Pitch Diameter Weld Base

Description
Diameter: M5-M24 Length: 1/2", 1/2", 1", 1-1/8", 1-1/2",2", 2-1/8" Etc.
Application: WELDER Market: For EU Countries
High Light:

copper plated insulation pins

,

cd weld pins



                   Stainless Steel Partial Thread ARC Welding Studs With A Pitch Diameter Weld Base



1. Introduction & Specifications



Partial Thread: The studs have a pitch diameter weld base.
Diameter: Available in diameters from 1/4” through 1”.
Length: Length is before weld.

             Stud diameters 1/2” and smaller will be approximately 1/8” shorter after welding.

             Diameters of 5/8” and larger will be approximately 3/16” shorter after welding.
Material: Mild steel Or Stainless Steel

Typical Use : Where both minimum fillet and full thread strength are required



2. Specification Of The Partial Thread ARC Welding Studs





Stainless Steel Partial Thread ARC Welding Studs With A Pitch Diameter Weld Base 0

T

A

B

L

Material

1/4-20

0.215"

3/8"

7/8",1.0",1.1/8",1.1/4",1.3/8",1.1/2",1.3/4",2"

mild steel. stainless steel

5/16-18

0.275"

3/8"

7/8",1.0",1.1/8",1.1/4",1.3/8",1.1/2",1.3/4",2"

mild steel. stainless steel

3/8-16

0.330"

3/8"

7/8",1.0",1.1/8",1.1/4",1.3/8",1.1/2",1.3/4",2",2.1/8", 2.1/2",3.0",3.1/2",4"

mild steel. stainless steel

1/2-13

0.448"

1/2"

1.1/8",1.1/4",1.3/8",1.1/2",1.3/4",2",2.1/8", 2.1/2",3.0"

mild steel. stainless steel

5/8-11

0.562"

5/8"

1.1/4",1.3/8",1.1/2",1.3/4",2",2.1/8", 2.1/2",3.0"

mild steel. stainless steel

3/4-10

0.680"

55/64"

1.1/2",1.3/4",2",2.1/8", 2.1/2",3.0",3.1/2",4"

mild steel, stainless steel



3. Material Details Of The Partial Thread ARC Welding Studs







MATERIAL

MILD STEEL

STAINLESS STEEL

C - 0.23% max.

P - 0.04% max.

AISI grade - 302/304/305/316 std.

Mn - 0.90% max.

S - 0.05% max.

Other grades available upon request.





MECHANICAL PROPERTIES

Tensile

60,000 psi (min.)



Values for various grades available upon request.

Yield

50,000 psi (min.)

Elongation

20% (in 2 inches)

PLATING

Plating is not standard. Cadmium, Copper, Nickel, and Zinc available upon customer request.





4. Features Of The Partial Thread ARC Welding Studs



For trouble free welding you will need to purchase high quality studs.

We stock and sell the full range of Arc Weld Studs in all the usual materials and sizes,

and with European and International standards for automatic stud welding.

We can also supply the less popular thread forms, in fact many of these are also held in stock.
Arc Weld Studs for hand and automatic feed must conform to BS EN ISO 13918 standard

for threaded, unthreaded and internal threaded studs.



5. Detailed Images
