Product Details:
|
| Product Name: | Stud Welding Pins | Size: | M3 - M10 |
|---|---|---|---|
| Material: | Stainless Steel, Mild Steel Aluminum | Surface: | Copper Plated , Galvanized |
| Surface Treatment: | Copper Plated Or Zinc Coating | Standard: | DIN |
| Grade: | 4.8,A2-70 | ||
| High Light: | cd weld pins,threaded stud welder |
||
Type: external thread, internal thread, one point, three points
Usage:Steel structures, bridge, highway, railway, tower structures, power station, airport constructions, etc
| Imperial Thread "D" |
Flange* Diameter "FD" |
Minimum Length "L" |
| 4-40 | .149 | .312 |
| 6-32 | .173 | .312 |
| 8-32 | .201 | .312 |
| 10-32 | .225 | .312 |
| 10-24 | .225 | .312 |
| 1/4-20 | .285 | .375 |
| 5/16-18 | .345 | .500 |
| 3/8-16 | .410 | .625 |
| Metric Thread "D" |
Flange* Diameter "FD" |
Minimum Length "L" |
| M4-.07 | 5.0 | 6.0 |
| M5-.08 | 6.0 | 10.0 |
| M6-.1.0 | 7.0 | 10.0 |
| M8-1.25 | 9.0 | 10.0 |
| M10-1.5 | 11.0 | 10.0 |
| Low Carbon Steel | Stainless Steel | |
| Material: | C1008-C1020 C-0.23% Max; P-0.04% Max Mn-0.90% Max; S-0.05% Max |
18-8 302Hq/304/304L Standard |
| Mechanical Properties: |
Min. Tensile Type A .....61,000 Psi (420 Mpa) Min. Yield Type A .....49,000 Psi (340 Mpa) |
Other Grades Available Upon Request |
| Plating: | Copper Plating Is Standard | Plating Does Not Apply To Stainless Steel |
| Annealing: | Studs Are Annealed Where Required | |
| Aluminum: | 1100, 6061 And 5000 Series | Brass Alloy - Lead Free 70-30 In Standard |
1. Certification: ISO, ROHS, SGS
2. Available Standard: DIN, ANSI, ASTM, JIS, BSW
3. Strength: Grade 4.8,Grade 8.8,Grade10.9,Grade12.9 A2-70, A4-70, A4-80
4. Finishing: Yellow, blue, white zinc plated, Galvanized,HDG,Chromate,Dacromet
5. Available material: Carbon steel, stainelss steel SS304, A2 ,Stainless steel SS314,A4.
6. Size: M2-M100, Length: 5-300mm, Moq: 500pcs, Port: Shenzhen, Shanghai
7. Available Packing: Plastic bags+Chipboard Cartons+Plywood pallet with Belt &Film.
