Home ProductsSelf Adhesive Insulation Pins

Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool

Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool

  • Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool
  • Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool
  • Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool
  • Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool
Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool
Product Details:
Place of Origin: China
Brand Name: HUIHAO
Certification: ISO9001:2008
Model Number: Self Adhesive Insulation Pins
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Packaging Details: 500 pcs per carton ,48 cartons on one pallet
Delivery Time: 12 days after the first payment
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100,000 pcs per week
Contact Now
Detailed Product Description
Product Name: Self Adhesive Insulation Pins Material: Galvanized Steel , Stainless Steel , Aluminum
Pin Dia: 0.106'' As Standard Base Size: 50mmx50mm As Standard
Pin Length: 25mm - 200mm ,could Be Customized Sticker Color: White , Red,blue In Common
High Light:

insulation pins and washers

,

insulation wall plugs



Double Face Tape Self Adhesive Insulation Pins12ga Dia with Clip Fix Glass wool



Quick details of self adhesive insulation pins



Self Adhesive Insulation Pins are installed with the double face tape, the insulation is impaled over the

spindle & secured with a self-locking washer.



Self Adhesive Insulation Pins are designed to fix efficiently insulation on smooth surfaces such as air

ducts, attenuators, chambersand enclosures. It consists of a pin, firmly mounted on a high quality self

adhesive base.



Detail Specification Of Self Adhesive Insulation Pins:



Material:Galvanized steel in common, also could be stainless steel and aluminum

Tape color: red, white, blue, etc



 HUIHAO Self Adhesive Insulation Pins



Pin diameter  Base size  Pin length in common Clips Size
12 Ga (2.7mm or 0.106'') 50mmx50mm 1'' 22mm - 40mm, 35mm in common
12 Ga (2.7mm or 0.106'') 50mmx50mm 2'' 22mm - 40mm, 35mm in common
12 Ga (2.7mm or 0.106'') 50mmx50mm 2 1 / 2'' 22mm - 40mm, 35mm in common
12 Ga (2.7mm or 0.106'') 50mmx50mm 3 1 / 2'' 22mm - 40mm, 35mm in common
12 Ga (2.7mm or 0.106'') 50mmx50mm 4'' 22mm - 40mm, 35mm in common

12 Ga (2.7mm or 0.106'')

50mmx50mm 5 1 / 2'' 22mm - 40mm, 35mm in common
12 Ga (2.7mm or 0.106'') 50mmx50mm 8'' 22mm - 40mm, 35mm in common
The Self Stick Adhesive Insulation Anchors also could be produced as request via from material, pin dia and length.



Advantages of the Self Adhesive Insulation Pins



1. Environmentally-friendly

2. Light, dust free, fire retardant and easy to install

3. Heat reflection, heat insulation, sound insulation, counter radiation, counter vibration and shielding

4. During Summer: moisture barrier, sun protection, waterproof, energy saving consumed by cool air conditioning

5. During Winter: heat protection, remarkable energy saving consumed by warm air conditioning

Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool 0Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool 1

Self Adhesive Insulation Pins USE:



These hangers are designed to mechanically hold insulation material to various surfaces. It is very important for the

user to determine the suitability of this product for each application. Discretion must be used in application, and we

recommend that the user first perform a test application to satisfy himself of the desirability of using the product for the

user’s particular purpose.



Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool 2

Self Adhesive Insulation Pins CAUTION:



The user is responsible for determining the suitability of the application. Hangers must be applied to a clean, dry,

non-porous surface that is free of all oil, films, dust, rust, etc. Self-adhering hangers are not recommended for concrete

or painted surfaces. It is important that they not be used where operating temperatures can exceed 150° F at the point

of adhesion. Hangers should not be used on ceilings or roofs of metal buildings or any surface the reverse side of which

may be exposed to heat concentration from sunlight, etc., direct or otherwise. Load per anchor should not exceed 3 lbs.

Packaging methods of the Self Adhesive Insulation Pins

The default packaging way is bulk packing or small boxes packing in cartons then on Pallets.
We can assist you in determining the most effective packaging style, material, and size for your unique products

or as your requirement.




HUIHAO HARDWARE

Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool 3

Double Face Tape Self Adhesive Insulation Pins 12Ga Dia With Clip Fix Glass Wool 4
